Tsev - Khoom - Planetary Gearbox - GPB Series - Paub meej

GPB Series

Precision planetary gearbox is a new-generation product developed by our company, which integrates advanced technologies at home and abroad, its main features are as follows: 1.Low Noise: Under 65db. 2.Low Backlash: Backlash less than 3 arcmin for single stage. Less than 5 arcmin for two stages....

Xa kev nug Tsham tam sim no

Precision planetary gearbox is a new-generation product developed by our company, which integrates advanced technologies at home and abroad, its main features are as follows:

1.Low Noise: Under 65db.

2.Low Backlash: Backlash less than 3 arcmin for single stage. Less than 5 arcmin for two stages.

3.High Efficiency: Above 95% for single stage, above 92% for two stages.

4.High Input Speed: up to 8000 RPM.

5.High Torque: Higher torque output than conventional standard planetary gearboxes.

6.High Stability: Employs high tensile strength alloy steel. Gear hardening is made for the entire gear instead of only surface hardening,which extends gear service life and maintain high accuracy as new after a long period of operation.

7.High Reduction Ratio: with modular design. the planetary gear boxes can be interconnected, speed reduction ratio could be over 1/1000.

1.Aerospace, military industry.

2.Medical health, electronic information technology industry.

3.Industrial robots, Production automation, CNC machine tool manufacturing industry.

4.Motor, textile, printing, food, metallurgical, environmental protection engineering and warehouse logistics industry.
