Qhov no yog qhov Precision Right Angle Rotary Table qauv GSA200-05K-SV nrog gear ratio 1: 5 rooj loj 200 hli rau servo lub cev. Txoj kab lus Precision Right Angle Cov lus qhia ua rau kab thaiv thiab khi yooj yim dua thiab yooj yim, thiab qhov zoo ntawm qhov kev ua no yog tshwj xeeb tshaj li hauv cov qhov thaiv thiab qhov chaw nruab deg. Nrog nws lub zog siab tsim lub cev, nws muaj peev xwm dais qhov loj load axial ntau dua Hollow Teb Cov Lus Mus Txog 5000N.
1. Specification of Precision Right Angle Ntsuas Cov Rooj Lus GSA200-05K-SV
Parameter | ||
Tsav Yam | Hom 750W SV Tsav | |
Permissible Torque | Nm | 80 |
Permissible Input Speed | rpm | 2000 |
Permissible Axial Load | N | 5000 |
Repeatability | sec | ± 5 (0.001 °) |
Platform Caij | hli | ± 0.005 |
Backlash | min | ≦ 1 |
Nyhav | kg | 18 |
Tsav Parameter | ||
Hom | Code | Qauv |
Fuji | F | GYS 751D5 |
Mitsubishi | M | HF-KFS-73 |
Panasonic | P | MSMD082G1U |
SANYO | S | Q1AA07075D |
Yaskawa | Y | SGMAH-08A |
Oriental | O | DX475 |
Delta | T | ECMA-C30807 |
* Lub cav servo yog teeb tsa los ntawm tus neeg muas zaub. Cov qauv saum toj no yog rau kev siv xwb
2. Precision Right Angle Rotary Table yog dab tsi?
3. Dab tsi yog qhov khoom ntawm Precision Right Angle Rotary Table?
4. Kev Kho Vaj Tse Ntawm Cov Phiaj Xwm Ntawm Txoj Cai Ncaj Ncees
5. Muaj pes tsawg tus qauv?
Yog xav paub ntxiv, thov mus saib daim Catalog. (download lub PDF hauv nplooj ntawv no)
6. Yuav Ua Li Cas thiaj Ua Tau Zoo Tshaj Lawm Nquag Zis?
Lub caij sib dhos ntawm Precision Right Angle Rotary Table nrog Planetary Reducer
Kev sib txuas ntawm Kev Ntsuas Ntawm Cov Ncauj Lus Cov Ncauj Lus Cov Lus Teb nrog Txoj Kev Ncaj Ncees (Right Angle Reducer)
7. Dab Tsi Ntaus Ntaus Dab Tsi Siv Cov Ncauj Lus Hauv Lus Ncaj Ncees?
Xav paub ntau video, thov nias qhov GIGAGER Youtube Channel: https://www.youtube.com/ playlist? List=PLT-2VrhPP3YItwfN_wA4YkS8bzfBpJu39
8. Yuav Xaiv Tus Xwm Ntawm Txoj Cai rau Kuv Tus Ntaus Li Cas?
Yog xav paub ntxiv txog cov qauv xaiv ntawm Hollow Rotary Actuator, thov saib ntawm Cov Qauv Xaiv Cov Qauv Hauv Kem.
9. Yuav ua li cas rau nruab ib lub Servo Tsav mus rau Precision Right Angle Cov Lus Teb?
Thov mus saib Catalog lossis tiv tauj peb kev muag khoom.
10. Vim li cas thiaj xaiv GIGAGER?
11. Lus nug
Lus Cim 1: Chav Txauv ntawm Torque
Torque Chav | 1 Nm | 1 N.cm | 1 kgf.m | 1 kgf.cm | 1 lbf.ft | 1 lbf.in |
1 Nm | 1 | 102 | 0.10197 | 10.197 | 0.7376 | 8.8509 |
1 N.cm | 10-2 | 1 | 1.0197 × 10-3 | 0.10197 | 7.376 × 10-3 | 8.8509 × 10-2 |
1 kgf.m | 9.8066 | 980.665 | 1 | 102 | 7.233 | 86.79 |
1 kgf.cm | 9.8066 × 10-2 | 9.8066 | 10-2 | 1 | 7.233 × 10-2 | 0.8680 |
1 lbf.ft | 1.356 | 1.356 × 102 | 0.1383 | 13.83 | 1 | 12 |
1 lbf.in | 0.113 | 11.3 | 1.152 × 10-2 | 1.152 | 8.333 × 10-2 | 1 |
Lus Cim 2: Lub Pem Hauv Ntej
Lub Pem Hauv Paus | Tus nqi | Cim | Shorthand |
Degree | 1/360 Vajvoog | ° | Deg |
Arc nas | 1/60 degree | '(Thawj tus lej) | arcmin, amin, MOA |
Arc-thib ob | 1/60 arcmin | "(Ob chav prime number) | arcsec |
1/1000 Arc Thib Ob | 1/1000 arcsec | mas |
